technical sheet
ref.:
rev. no.:
date:
page:
Blocfor®
20-ft. (6 m) self-retracting web lifeline
T-4642C
3
09/09
1/2
The Blocfor® 20-ft. (6 m) self-retracting web lifeline provides freedom of movement to workers performing their job at various heights. This device performs a tethering function while allowing vertical movement to the maximum working length of 20 ft. (6 m). The Blocfor® 20 ft. (6 m) will arrest a fall by locking the drum when quick movement is experienced and is designed to minimize the fall distance and impact force.
For further information, refer to the Use and Maintenance Instructions for the Blocfor® 20-ft. (6 m) self-retracting web lifeline.
WARNING
A minimum of 5.25 ft. (1.6 m) safety clearance is required below the user s feet (working surface).
Features
" Thermal plastic housing for excellent shock mitigation
" Ergonomic shape
" Inertia lock provides very fast stop
" Self-locking 3 D4-in. (19 mm) swivel hook
Applications
" Utilities
" Service and maintenance
" Ladder climbing
" Construction sites
" Any elevated work station
RS20WSA/E4
Applicable standards
" Meets CSA Z259.2.3-04 with CSA Z259.11-05,
class E4 or class E6 approved shock absorber
Available model that meets CSA Z259.11-05, class E4
with a capacity of 100 to 254 lbs. (45 to 115 kg)
RS20WSA/E4 20-ft. (6 m) Blocfor® synthetic web self-retracting lifeline with shock absorber mounted above the self-retracting lifeline
