Flail Cutter | Attachments
Flail Cutter | Specifications
Standard features
" Variable-speed displacement motor allows the flail cutter to be "tuned in" to your machine, depending on its hydraulic capacity. By varying the motor displacement to accept auxiliary hydraulic flows ranging from 64 to 140 l/min, the flail cutter can be operated on many different carriers.
" Floating linkage is standard on the flail cutter. This, along with the attachment's compact deck length, lets the unit follow the contour of the land regardless of the pitch or attitude of the carrier, permitting the cutter up to ten degrees of oscillation.
" Safety compliance The flail cutter complies with the SAE J1001 standard for industrial flail mowers. It is standard-equipped with an automatic shut-off device which allows approximately ten inches of vertical travel in the Bob-Tach!"; mounting system before the flail cutter shuts down.
" Full-width tapered rear roller provides greater turning ability during operation.
" Adjustable rear hatch allows operators to vary the size of discharged material, ranging from small, for mulching applications to coarse for high-performance cutting.
Flail cutter FC155
Flail cutter FC175
Item number
7115498
7108385
Flail cutter FC200
7101894
Applications
"
"
"
"
"
"
Municipal jobs
Forestry
Parks
Landscaping
Nurseries
Hobby farmers
Compatible with loader
S130, S150, S160, S160H, S175, S175H, S185, S185H, S205, S205H, T140, T190, T190H
S175, S175H, S185, S185H, S205, S205H, S220, S220H, S250, S250H, S300, S330, S300H, S330H, S630, S630H, S650,
S650H, S770, S770H, S850, S850H, A300, A300H, A770, A770H, T190, T190H, T250, T250H, T300, T320, T300H, T320H,
T650, T650H, T770, T770H, T870, T870H
S175, S175H, S185, S185H, S205, S205H, S220, S220H, S250, S250H, S300, S330, S300H, S330H, S630, S630H, S650,
S650H, S770, S770H, S850, S850H, A300, A300H, A770, A770H, T190, T190H, T250, T250H, T300, T320, T300H, T320H,
T650, T650H, T770, T770H, T870, T870H
