S205

Extrait du fichier (au format texte) :

S205

Compact Loaders

S205

Specifications
Attachments

Rated operating capacity
Tipping load (ISO 14397-1)
Pump capacity
Pump capacity  high flow option
System relief at quick couplers
Max. travel speed (low range)
Max. travel speed (high range - option)

1009 kg
2019 kg
62.0 l/min
96.5 l/min
22.4 23.1 MPa
11.6 km/h
18 km/h

Make / Model
Fuel / Cooling
Power
Torque at 1425 RPM (SAE JI 995 Gross)
Number of cylinders
Displacement
Fuel tank capacity

Kubota / V2607-DI-TE3B-BC-I
Diesel / Liquid
45.5 kW
218 Nm
4
2600 cm3
90.8 l

Operating weight

3023 kg

Vehicle steering
Loader hydraulics tilt and lift

Direction and speed controlled by two hand levers
Separate foot pedals, optional Advanced Control System (ACS)
